Description
Technical Specifications
| Imported By | Havells India Ltd | Country Of Origin | China |
| Maximum Efficiency | 97.50 % | Self Consumption at Night | < 1 W |
| Cooling | Natural | Degree of Protection | IP65 |
| Dimensions (L×W×H) | 30.3 cm × 26 cm × 11.8 cm | Operating Temperature Range | -30°C to +60°C |
| Topology | Transformer Less | Weight | 5.5 kg |
| Max Input Current Per MPPT | 12 A | Maximum DC Input Short Circuit Current Per MPPT | 15 A |
| Maximum Input Voltage | 500 V | MPPT Operating Voltage Range | 50 V – 500 V |
| Rated Input Voltage | 360 V | Grid Frequency Range | 45 Hz – 55 Hz |
| Grid Voltage Range | 180 V AC – 276 V AC | Maximum AC Power | 1100 VA |
| Maximum Output Current | 5.3 A | Nominal Grid Voltage | L/N/PE, 220 V AC, 230 V AC, 240 V AC |
| Rated Output Current | 4.8 A | Rated Power | 1100 W |
